Brand: GE Description: IS200JPDFG1ADD Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 3 Payment Term: T/T Shipping Port: Xiamen The IS200JPDFG1ADD is a 125 V DC power distribution module designed for use in the GE Mark VIe control system. GE IS200JPDFG1ADD forms a critical part of the Power Distribution Module (PDM) family, responsible for accepting and distributing 125 V DC power from battery sources and/or AC-to-DC conversion modules (DACA).
|
Manufacture |
GE |
|
Model Number |
IS200JPDFG1ADD |
|
Ordering Number |
IS200JPDFG1ADD |
|
Catalog |
Mark VIe |
|
Description |
Power Distribution board |
|
Country Of Origin |
USA |
|
HS CODE |
8537101190 |
|
Dimension |
233 × 37 × 160 mm |
|
Weight |
0.82 kg |
Technical Parameters
Input Voltage: 24 V DC or 125 V DC (only one input can be used at a time)125 V DC nominal (max 145 V DC)
Input Current: 30 A maximum
Circuit Breaker: 30 A DC, included
Output Connectors: J1R, J1S, J1T (5 A fused), J7X,Y,Z (5 A fused), J8A,B (12 A fused), J12 (3 A fused)
Fuse Rating: 15 A, 250 V (¼ in x 1¼ in fuse)3 A to 12 A, depending on outputImpedance to Ground: >75 kΩ (JP1 in place), >1500 kΩ (JP1 removed)
Operating Temperature: -30°C to +65°C (-22°F to +149°F)
Module Dimensions: 30.48 cm H x 21.33 cm W x 16 cm D (12" x 8.4" x 6.3")
Mounting: 4 x #10 screw holes
Product Overview
The IS200JPDFG1ADD is a 125V DC power distribution module, specifically designed for the GE Mark VIe control system. As a key component of the Power Distribution module (PDM) series, it is responsible for receiving and distributing 125V DC power from the battery and/or AC-DC conversion module (DACA). The board is specifically designed for high-reliability applications where redundant power supplies and system monitoring are of crucial importance. This board can be seamlessly integrated with other PDM components and provide comprehensive feedback through the PPDA I/O interface to achieve real-time system diagnosis.
Functional Features
Redundant power input, DACA module supporting 125V DC battery input and AC power supply for backup power.
Floating DC busbar, supporting ground fault detection, complies with non-hazardous live electrical standards.
Integrated monitoring, providing voltage amplitude, ground fault and AC-to-DC detection through PPDA.
Fuse and switch output, multiple output circuits, equipped with fuses and switches for branch protection.
System feedback is connected to the PPDA using a flat cable for real-time diagnosis and status reporting.
High reliability, specifically designed for redundant configurations to ensure continuous operation.
Comparison with Similar Products
|
Feature |
IS200JPDFG1ADD |
JPDE (24/48 V DC) |
JPDB (AC Distribution) |
|
Input Type |
125 V DC |
24/48 V DC |
115/230 V AC |
|
Outputs |
Multiple fused DC outputs |
Fused DC outputs |
Fused AC outputs |
|
Ground Fault Detect |
Yes |
Yes |
No |
|
PPDA Feedback |
Full analog & digital feedback |
Limited analog feedback |
AC voltage & branch status feedback |
|
Redundancy Support |
Yes (battery + DACA) |
Yes (dual supplies) |
Yes (dual AC sources) |
|
Typical Use Case |
High-power DC distribution |
Low-power DC distribution |
AC load distribution |
Advantages & Disadvantages
Advantage
High reliability is reflected in supporting redundant power supplies and fault-tolerant operation.
The safety complies with the non-hazardous live standards and is equipped with a ground fault detection function.
The modular design can be easily integrated with other Mark* VIe PDM components.
The powerful protection functions include fuses, circuit breakers and filters to ensure safe operation.
Disadvantage
The installation is complex and requires correct grounding and connection to the PPDA to fully function.
IS200JPDFG1ADD is not an independent product. GE Power Distribution board must be used in a compatible GE system.
Compared with non-redundant or simpler distribution boards, the initial cost of the GE system is higher.
Technicians must be familiar with the GE PDM architecture in order to troubleshoot.
