Brand: GE Description: IS200SPIDG1ABA Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 12 Payment Term: T/T Shipping Port: Shenzhen GE IS200SPIDG1ABA Captures and time- stamps high- speed pulse signals (e.g. speed pickups, blade- tip probes) alongside conventional discrete inputs for advanced sequence- of- events recording and protection logic.
|
Manufacture |
GE |
|
Model Number |
IS200SPIDG1ABA |
|
Ordering Number |
IS200SPIDG1ABA |
|
Catalog |
Mark VI |
|
Description |
GE IS200SPIDG1ABA Simplex Funct ID Board |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
178 × 330 × 160 mm |
|
Weight |
0.42 kg |
Technical Parameters
Pulse Inputs:
8 × TTL/CMOS compatible high- speed inputs for the GE IS200SPIDG1ABA
Voltage range: 0–5 V DC; max frequency: 100 kHz
Input current: 2 mA per channel
Discrete Inputs:
8 × 24 V DC wetting- voltage inputs (18–32 V V DC)
Input current: 2.5 mA per channel; 4 ms hardware debounce in the GE IS200SPIDG1ABA
Sampling & Timing:
Synchronous sampling across all channels
Timestamp resolution: 1 µs
Buffering: On- board FIFO for event capture, up to 4 K events
Isolation: Reinforced channel- to- channel and channel- to- ground (> 1 kV)
Connectors:
Dual 50- pin backplane edge connectors
Field wiring via two 26- position pluggable terminal blocks
Environmental:
Operating Temp: –30 °C to +65 °C
Storage Temp: –40 °C to +85 °C
Humidity: up to 95 % RH, non- condensing for GE IS200SPIDG1ABA
Product function
Pulse- Gate Interface: Conditions and digitizes rotor- speed or blade- tip probe pulses with microsecond accuracy.
Discrete- Gate Logic: Monitors auxiliary discrete signals (alarms, interlocks) in lockstep with pulse events.
Event Aggregation: Buffers and forwards combined event/time data over IONet to the Mark VIe CPU for sequence- of- events analysis and protection decisions.
Core supporting modules
I/O Pack Carrier: IS42xPSCAH1B supplying power and Ethernet backhaul
Controller Module: Mark VIe CPU (e.g., IS200TPROH1C) executing overspeed and sequencing logic for GE IS200SPIDG1ABA
Ethernet Switch: IS420ESWB series for backbone connectivity
Extension components
Pluggable Terminal Blocks: 26- way keyed blocks for pulse and discrete wiring, with shield- termination posts
DIN- Rail/Panel Kits: Adapter clips and brackets for 35 mm rail or cabinet- panel mounting
Shielding Accessories: Cable- shield clamps and ferrite cores for EMI suppression on high- speed signal leads
Spare Jumper Kits: Configuration jumpers for input- mode selection
Software support
Configuration:
Channel- mapping, debounce timing, and event- buffer size set via GE ToolboxST™ templates for GE IS200SPIDG1ABA
Diagnostics & Monitoring:
Real- time event counters, buffer- overflow flags, and channel- health indicators available in HMI and OPC- DA tags
Self- test on power- up with diagnostic logging in controller diagnostics
Firmware Updates: Delivered as part of Mark VIe system releases; applied via ToolboxST™
Documentation: Detailed in the GE Mark VIe/VIeS I/O Installation Guide and the Pulse & Discrete Gate Module Reference Manual
