Brand: GE Description: Conformal Coated Printed Circuit Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: ShenZhen GE IS210AEAAH1B provides a direct interface between the digital control system and the analog output devices like valves, motors, and actuators. Its reliability and its ease of diagnostics, along with sophisticated control capability, make it a fundamental component in the optimization of complex control systems.
|
Manufacture |
GE |
|
Model Number |
IS210AEAAH1B |
|
Ordering Number |
IS210AEAAH1B |
|
Catalog |
Mark VIe |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
40cm*30cm*5cm |
|
Packing Dimension |
42cm*32cm*7cm |
|
Weight |
1.2kg |
Technical Parameter
Power Supply Voltage: +18V to +48V DC.
Instantaneous Overcurrent Capacity: Twice the maximum continuous current.
Operating Temperature: -10°C to 60°C.
Storage Temperature: -20°C to 85°C.
Electrostatic Protection: 25 to 30 KV.
IONet Connectors:3.
Serial Port: One.
Functional Characteristics
Communication Interface: GE IS210AEAAH1B is the communication interface between POS and I/O boards and the IONet (IONet system control network). It allows for easy communication and interaction between the components of the architecture and ensures that all parts of a system are performing in unison.
VME Bus Master Control: GE IS210AEAAH1B acts as the VME bus master in the control and I/O boxes. The IDs are managed per system (rack) and the terminal boards.
Power Feedback Reception: It receives analog and digital power feedback from the J301 backplane connector. It enables the module to monitor power supply conditions and take actions required for stable operation.
Fault Diagnosis
Power Supply Check: Use a multi-meter to measure the input power supply voltage and confirm that it is within +18V to +48V. If the voltage is too high or too low, it can cause the GE IS210AEAAH1B to malfunction.
Communication Testing: Appropriate testing tools should be used to verify the communication state of both connectors and the serial port, so that we only use elements that we already confirmed can communicate with each other. Once you have done, then send some test signals and see if module is able to receive and transmit data properly.
Software Diagnosis: Check for error messages relevant to GE IS210AEAAH1B by using GE's provided configuration and monitoring software. Detailed information about communication errors, hardware failures or other problems might be included in the software.
Application Fields
Wind Turbine Control: Mostly operates inside the control systems of wind turbines. GE IS210AEAAH1B is essential for the operation of wind turbines, such as controlling the pitch angle of the wind turbine blades, the speed of the generator and the overall safety and stability of the wind power generation system.
Industrial Automation Systems: It can be used in many industrial automation situations where the capability of the communication to process the information is high and reliable. For instance, in the control systems of production line, it can make the informative devices run in cooperating and enable the production procedure running effectively.
Power Generation and Distribution power plants and power distribution systems, it can be used to monitor and control power generation equipment, circuit breaker, and other devices. It contributes to the balanced functioning of the power grid and the stable supply and distribution of electrical energy.
