Brand: GE Description: IS215ACLEH1B Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 12 Payment Term: T/T Shipping Port: Shenzhen GE IS215ACLEH1B Provides the primary AC mains connection, EMI/RFI filtering, surge protection, and isolation for GE Speedtronic Mark VIe/VIeS control cabinets.
|
Manufacture |
GE |
|
Model Number |
IS215ACLEH1B |
|
Ordering Number |
IS215ACLEH1B |
|
Catalog |
Mark VI |
|
Description |
GE IS215ACLEH1B Application Control Layer Module |
|
Country Of Origin |
USA |
|
HS CODE |
8537101190 |
|
Dimension |
233 × 160 × 60 mm |
|
Weight |
0.34 kg |
Technical Parameters
Input Voltage:
120 VAC ±10% @ 50/60 Hz
240 VAC ±10% @ 50/60 Hz (switch-selectable)
Current Rating: Up to 3 A continuous per input feed
EMI Filter: Complies with IEC 61000-4-5 Level 3 surge immunity and CISPR 22 Class A conducted emissions
Surge Protection: MOV array with thermal-fuse backup
Isolation Transformer: 1:1 winding providing ≥2 kV isolation between mains and control backplane (GE IS215ACLEH1B)
Redundant Feeds: Dual AC inputs diode-OR'd for high-availability power entry
Connectors:
Front-panel screw-terminal block for L, N, Earth
Backplane VME-64x edge connector to power backplane
Operating Temp: –20 °C to +70 °C
Storage Temp: –40 °C to +85 °C
Humidity: Up to 95 % RH, non-condensing
Product function
Line Conditioning: Attenuates conducted EMI/RFI and suppresses transients to protect sensitive electronics.
Surge Clamping: GE IS215ACLEH1B diverts overvoltage spikes to chassis ground via MOVs.
Galvanic Isolation: Ensures safety and noise rejection between external mains and internal DC modules.
Redundancy Support: Allows two independent mains feeds for uninterrupted operation.
Core supporting modules
DC Power Supplies: IS210AEPSG1A series that generate regulated +5 V, +12 V, +24 V rails.
Power-Distribution Feedback: GE IS215ACLEH1B IS220PPDAH1A for monitoring AC-sense and DC-sense signals.
I/O Pack Carriers: IS42xPSCAH1B providing power and IONet connectivity.
Controller Module: Mark VIe CPU (e.g., IS200TPROH1C) orchestrating power diagnostics and HMI integration.
Extension components
Field-Replaceable Fuses: Ceramic-fuse cartridges and holders for input protection.
Surge-Suppressor Modules: Plug-in TVS cartridges for enhanced transient immunity (GE IS215ACLEH1B).
Grounding Accessories: Braided copper straps and chassis-mount clamps for earth bonding.
Transformer Service Kits: Hot-swap isolation transformer assemblies for field maintenance.
Software support
Configuration: Fully hardware-based; no user configuration required.
Diagnostics & Monitoring:
AC-presence and surge-event counters reported via GE IS215ACLEH1B PPDA feedback to controller diagnostics.
Alarms and event logs viewable in GE ControlST™/ToolboxST™ and OPC-DA/HMI tags.
Documentation: Detailed procedures in the GE Mark VIe/VIeS Power Entry & Filter Module Manual and Power-Distribution Shelf Installation Guide.
