Brand: GE Description: IS215UCCCM04A Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 12 Payment Term: T/T Shipping Port: Shenzhen GE IS215UCCCM04A Designed to consolidate and route process- control data among diverse fieldbus and Ethernet- based networks within turbine- control cabinets.
|
Manufacture |
GE |
|
Model Number |
IS215UCCCM04A |
|
Ordering Number |
IS215UCCCM04A |
|
Catalog |
Mark VI |
|
Description |
GE IS215UCCCM04A Compact PCI Controller Board |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
233 × 160 × 50 mm |
|
Weight |
0.45 kg |
Technical Parameters
Communication Ports:
2 × 10/100Base- T Ethernet (RJ- 45) for IONet and auxiliary LAN
2 × RS- 485 ports (Modbus RTU/ASCII) on pluggable terminal block
1 × RS- 232 console port (DB- 9)
GE IS215UCVGM06A Protocols Supported: Modbus RTU/ASCII, Modbus TCP, OPC DA, PROFIBUS DP master/slave, PROFINET I/O, EtherNet/IP adapter
Buffering & Throughput:
64 MB SDRAM for message buffering
Aggregate throughput up to 200 Mbps
Power: 24 V DC via backplane (0.5 A max)
Isolation: 2 kV channel- to- ground on all serial ports; 1 kV between Ethernet ports and I/O circuits
Environmental:
Operating Temp: –40 °C to +70 °C
Storage Temp: –55 °C to +100 °C
Humidity: up to 95 % RH, non- condensing
Product function
Acts as a universal gateway and protocol- converter, mapping data among multiple fieldbuses and Ethernet networks into deterministic IONet frames. GE IS215UCVGM06A supports mixed- protocol environments—enabling seamless data exchange between legacy instruments and modern control- system servers without additional external routers or fiber- links.
Core supporting modules
I/O Pack Carrier: IS42xPSCAH1B providing backplane power and IONet connection
Controller Module: Mark VIe CPU (e.g., IS200TPROH1C) hosting configuration and routing logic
Ethernet Switch: IS420ESWB series for network distribution and redundancy
Extension components
Pluggable Terminal Blocks: GE IS215UCVGM06A 12- way blocks for RS- 485 wiring, keyed to prevent mis- insertion
DIN- Rail/Panel Mount Kits: Clips and brackets for mounting in non- VME enclosures or control panels
Shielding Accessories: Cable- shield clamps and ferrite cores for EMI/RFI suppression on serial links
SFP Adapter Kit: Optional SFP cages for fiber-optic uplinks on Ethernet ports
Software support
Configuration Tool: GE ToolboxST™ with Communication- Module Wizard for protocol assignment, mapping tables, and routing rules
Diagnostics & Monitoring:
Per- port link- status and error counters accessible via HMI and OPC tags
Real- time message- latency and buffer- usage statistics logged in controller diagnostics
Firmware Updates: Via ToolboxST™ or TFTP; supports secure rollback and CRC verification
Documentation: Detailed in the GE Mark VIe/VIeS I/O Installation Guide and the Universal Communication Module Reference Manual
