Brand: GE Description: IS215UCVDH7AM Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 13 Payment Term: T/T Shipping Port: Shenzhen GE IS215UCVDH7AM Used to provide precision drive signals and diagnostics for electro- hydraulic control valves in gas- turbine and combined- cycle plants.
|
Manufacture |
GE |
|
Model Number |
IS215UCVDH7AM |
|
Ordering Number |
IS215UCVDH7AM |
|
Catalog |
Mark VI |
|
Description |
GE IS215UCVDH7AM (DS200UCVAH1ABC) Status & Communication Card |
|
Country Of Origin |
USA |
|
HS CODE |
7326909000 |
|
Dimension |
233 × 160 × 50 mm |
|
Weight |
0.52 kg |
Technical Parameters
Output Channels: 8 independent ±20 mA current- loop or 0–10 V voltage outputs (jumper- selectable)
Resolution & Accuracy:
16- bit DAC per channel
± 0.05 % full- scale accuracy
Update Rate: Up to 500 updates/sec per channel
Diagnostics:
Per- channel load- current sensing (open- loop, short- circuit detection)
Valve- position feedback monitoring via auxiliary input channel
Isolation: Reinforced channel- to- channel and channel- to- ground (> 1 kV)
Input Supply: 24 V DC nominal (18–32 V DC range), 2 A max (via backplane)
Environmental:
Operating Temp: –30 °C to +65 °C
Storage Temp: –40 °C to +85 °C
Humidity: up to 95 % RH, non- condensing
These specifications belong to GE IS215UCVDH7AM.
Product function
GE IS215UCVDH7AM generates precise, time- synchronized control- valve drive signals under direction of the Mark VIe CPU. Integrates closed- loop diagnostics to verify actuator load and response, reporting valve- health status and alarms over the IONet bus. Supports both current- and voltage- mode outputs to suit a range of valve- positioner technologies.
Core supporting modules
I/O Pack Carrier: IS42xPSCAH1B power/carrier assembly (provides 24 V DC and IONet connections)
Controller Module: Mark VIe CPU (e.g., IS200TPROH1C) hosting the turbine- governor and valve- control algorithms
Feedback Packs: RTD and thermocouple input boards for process- variable monitoring (e.g., IS220PRTDH1A, IS230STTCH2A)
This configuration interfaces with GE IS215UCVDH7AM.
Extension components
Pluggable Terminal Blocks: 16- way screw- clamp blocks keyed to prevent mis- insertion; shield- termination posts for signal integrity
DIN- Rail & Panel- Mount Kits: Adapter clips and angle brackets for OEM or retrofit installations
Shielding Accessories: Cable- shield clamps and ferrite cores for EMI/RFI suppression on long valve- cabling runs
Calibration Fixtures: Loop calibrators for zero/span setup and valve- position feedback tuning
All accessories apply to GE IS215UCVDH7AM.
Software support
Configuration & Calibration:
Output- mode (current/voltage), range, and filter- settings defined via GE ToolboxST™ templates
On- line calibration wizard for dead- band and gain adjustments per channel
Diagnostics & Monitoring:
Real- time load- OK, open- loop, and short- circuit flags accessible through HMI, OPC- DA tags, and controller- diagnostics screens
Event logging for valve- position deviations and drive- signal anomalies
Firmware Updates: Delivered as part of Mark VIe system releases; applied via ToolboxST™ or USB interface
Documentation: Detailed in the GE Mark VIe/VIeS I/O Installation Guide and the Control- Valve Drive Module Reference Manual
Software functions configure GE IS215UCVDH7AM.
