Brand: GE Description: IS220PSCHH1A Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 14 Payment Term: T/T Shipping Port: Shenzhen GE IS220PSCHH1A Specialized Serial Communication Module Provides robust, multi channel serial communication for GE Mark VIe turbine control I/O packs. It routes asynchronous data streams between the IONet Ethernet backbone and field bus or point to point serial devices, ensuring reliable, real time data transfer in harsh industrial environments.
|
Manufacture |
GE |
|
Model Number |
IS220PSCHH1A |
|
Ordering Number |
IS220PSCHH1A |
|
Catalog |
Mark VIe |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
110 × 90 × 30 mm |
|
Weight |
0.35 kg |
Technical Parameters
Part Number: IS220PSCHH1A
Technology: Surface-mount PCB module
Serial Channels: 6 independent, configurable transceiver channels
Support for RS-232, RS-422, and RS-485 (half-duplex) protocols
Common-Mode Voltage Range: ± 5 V
Analog Voltage Inputs: 6 (for baud-rate/format monitoring)
Operating Temperature: 0 °C to +60 °C
Storage Temperature: –40 °C to +85 °C
Humidity: Up to 95 % RH, non-condensing
Power: Passive board (powered via I/O-pack backplane); no dedicated supply
Connectors: Edge-card connector to I/O pack backplane; external serial wiring via accessory terminal board
Product function
GE IS220PSCHH1A Specialized Serial Communication Module Provides robust, multi-channel serial communication for GE Mark VIe turbine-control I/O packs. It routes asynchronous data streams between the IONet Ethernet backbone and field-bus or point-to-point serial devices, ensuring reliable, real-time data transfer in harsh industrial environments.
Core supporting modules
Typically installed within a Mark VIe I/O pack chassis alongside:
I/O Pack Carrier: IS42xPSCAH1B or similar power-and-carrier pack
Controllers: Mark VIe CPU modules (e.g., IS200TPROH1C)
GE IS220PSCHH1A Complementary I/O Boards:
Analog I/O (e.g., IS230TAI* series)
Discrete I/O (e.g., IS400TRLYS* relay boards)
Extension components
GE IS220PSCHH1A Accessory Terminal Boards: Provide DB-9 or screw-terminal interfaces for each serial channel (e.g., IS40ySSCAH1A/SSCAH2A series)
DIN-Rail Adapter Kits: Mounting brackets for securing I/O packs in control panels
Shielding Accessories: Cable-shield clamps and ferrites for EMI suppression
Replacement Transceivers: Field-replaceable transceiver modules for serviceability
Software support
Configuration: Channel modes and parameters set via GE ControlST™/ToolboxST™ when engineering the I/O pack; no on-board user interface
Monitoring & Diagnostics:
Loop-health and error counters accessible through controller diagnostics
Real-time status reported in HMI alarms or OPC-DA tags
Protocols: Transparent layer-2 forwarding; serial-to-Ethernet tunneling handled by I/O-pack firmware
Firmware Updates: Delivered as part of Mark VIe system software revisions; applied via ToolboxST™
Documentation: Detailed in GE Mark VIe I/O Installation Guide and the “Specialized Serial Communication Module” section of the I/O-Pack Reference Manual
