GE IS220PTCCH1B 12 Combustion Optimized Inputs

Technical Parameters

Channels: 12 analog input channels, optimized for combustion sensors

GE IS220PTCCH1B Input Types & Ranges:

4–20 mA current inputs (passive, external excitation required)

Thermocouple inputs (J, K, T types) with cold-junction compensation

Voltage inputs: 0–10 V DC

Accuracy: ± 0.1 % of full scale

Resolution: 16 bits per channel

Sampling Rate: 200 samples/sec per channel (simultaneous)

Isolation: Reinforced channel-to-channel and channel-to-ground galvanic isolation

Filtering & Response:

Programmable low-pass filter (up to 50 Hz)

Hardware overvoltage protection to ± 35 V

Connector: Right-angle header accepting 52-position pluggable terminal block

Environmental:

Operating Temp: –30 °C to +65 °C

Storage Temp: –40 °C to +85 °C

Humidity: Up to 95 % RH, non-condensing

Product function

GE IS220PTCCH1B 12 Combustion Optimized Inputs and conditions multiple combustion-related analog signals—such as flame-scanner currents, pressure-transmitter outputs, and thermocouple voltages—and forwards digitized data over the IONet Ethernet bus to the Mark VIe control CPU. Ensures low-latency, high-accuracy feedback for combustion-control algorithms and safety interlocks..

Core supporting modules

I/O Pack Carrier: Power & carrier module (e.g., IS42xPSCAH1B)

CPU Modules: Mark VIe controller (e.g., IS200TPROH1C)

Complementary I/O Boards:

Relay-output (IS400TRLYS1B)

Discrete-input (IS200TICIH2A)

Specialized serial (IS220PSCHH1A)

Extension components

Pluggable Terminal Blocks: Screw-clamp field-wiring blocks keyed for error-proof insertion

DIN-Rail & Panel Mount Kits: Optional angle brackets and clips for 35 mm rails or panel installations

Shielding Accessories: Cable-shield clamps and ferrite cores for EMI suppression

Snubber & Suppression Kits: RC networks for protection of thermocouple and pressure-transducer signals

Software support

GE IS220PTCCH1B Configuration & Calibration:

Set up via GE ControlST™/ToolboxST™ with pre-defined templates for combustion loops

On-line calibration wizard for sensor scaling and thermocouple cold-junction offsets

GE IS220PTCCH1B Diagnostics & Monitoring:

Real-time channel-health status and error counters accessible in HMI and OPC-DA tags

Automated self-test on power-up with alarm reporting in controller diagnostics

Firmware: Board-level I/O firmware maintained as part of Mark VIe system updates; loaded via ToolboxST™

Documentation: Detailed in GE Mark VIe/VIeS I/O Installation Guide and the “Combustion-Optimized Input” section of the I/O Pack Reference Manual.
