Brand: GE Description: IS230JPDGH1A (IS200JPDGH1ABC) Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 12 Payment Term: T/T Shipping Port: Shenzhen GE IS230JPDGH1A DC power distribution, supports dual DC power supplies Installed in the power-distribution section of a Mark VIe control cabinet, the IS230JPDGH1A distributes and monitors DC control and wetting power to multiple I/O and logic boards.
|
Manufacture |
GE |
|
Model Number |
IS230JPDGH1A (IS200JPDGH1ABC) |
|
Ordering Number |
IS230JPDGH1A (IS200JPDGH1ABC) |
|
Catalog |
Mark VIe |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
178 × 330 × 160 mm |
|
Weight |
0.38 kg |
Technical Parameters
Nominal Input Voltage: 28 V DC (range 27.4–28.6 V)
Dual-Supply Support: Two independent diode-isolated 28 V DC inputs for redundancy
GE IS230JPDGH1A Output Circuits:
Control Power: 28 V DC @ board-specified load
Wetting Power: 24 / 48 V DC for contact-input packs
Sensing Channels: Two AC-voltage sense circuits (for monitoring AC distribution health)
Diagnostic Interface: Onboard 50-pin diagnostic connector (P2) to PPDA I/O pack
LED Indicators: Eight LEDs for board-ID and live-channel health/status
PCB Finish: Conformal-coated for moisture and contaminant resistance
Mounting: DIN-rail or bracket-mounted, vertical orientation recommended
GE IS230JPDGH1A Environmental:
Operating: –30 °C to +65 °C
Storage: –40 °C to +85 °C
Humidity: up to 95 % RH, non-condensing
Product function
GE IS230JPDGH1A DC power distribution, supports dual DC power supplies
GE IS230JPDGH1A Delivers and redundantly distributes DC control power to GE Mark VIe I/O packs and terminal boards, while supplying separate wetting voltages to discrete-input circuits. Simultaneously aggregates AC-distribution diagnostics and routes all feedback signals through the integrated PPDA pack interface, enabling automated health monitoring without manual configuration.
Core supporting modules
PPDA Feedback Pack: IS220PPDAH1A, plugs directly into the IS230JPDGH1A for power-system diagnostics
I/O Pack Carrier: IS42xPSCAH1B, provides backplane power and I/O-bus connectivity
Controller Module: Mark VIe CPU (e.g., IS200TPROH1C) for diagnostics aggregation and HMI reporting
Extension components
Ribbon-Cable Jumpers: 50-pin, keyed jumpers for PPDA-to-JPDG board connection
Mounting Hardware: Metal bracket and screw kit for vertical board installation
Replacement LED Kit: Spare channel-status LEDs and holders
DIN-Rail Adapters: Clips for mounting in standard 35 mm control-panel rails
Software support
Configuration: Fully automatic board-ID and channel mapping; no user setup required
Diagnostics & Monitoring:
Real-time power-supply health and AC-sense alarms visible in GE ControlST™/ToolboxST™
OPC tags for diagnostic data and fault counters
Firmware: None—entirely hardware-based distribution and sensing
Documentation: Detailed in the GE Mark VIe Power-Distribution Feedback Module Manual and general I/O Installation Guide
