GE IS230SNTCH2A

Technical Parameters

Channels: 12 isolated thermocouple inputs

Supported Types: J, K, T, E, R, S, B (selectable per channel)

Measurement Ranges:

Type J: –210 °C to +760 °C

Type K: –270 °C to +1372 °C

Type T: –270 °C to +400 °C

Type E: –270 °C to +1000 °C

Type R/S: –50 °C to +1768 °C

Type B: +0 °C to +1820 °C

Accuracy: ± 0.25 °C or ± 0.1 % of reading, whichever is greater

Resolution: 0.1 °C

Sampling Rate: 20 samples/sec per channel

Cold-Junction Compensation: Integrated digital per channel

Filtering & Protection:

Programmable low-pass filter up to 100 Hz

Hardware spike suppression and overvoltage clamp to ± 35 V

Reverse-polarity protection

Isolation: Reinforced channel-to-channel and channel-to-ground (> 1 kV)

Connector: Right-angle 52-position header for pluggable terminal block

Environmental Ratings:

Operating Temp: –30 °C to +65 °C

Storage Temp: –40 °C to +85 °C

Humidity: Up to 95 % RH, non-condensing

GE IS230SNTCH2Ameets all listed specifications.

Product function

GE IS230SNTCH2A conditions, linearizes, and digitizes thermocouple voltages into calibrated temperature readings. Delivers deterministic, low-latency temperature data over the IONet Ethernet bus to the Mark VIe CPU, supporting real-time control, safety-trip logic, and trend-analysis functions without manual board-level adjustments.

Core supporting modules

I/O Pack Carrier: IS42xPSCAH1B power/carrier assembly providing backplane power and Ethernet interfaces

Controller Module: Mark VIe CPU (e.g., IS200TPROH1C) for data aggregation and control logic

Complementary I/O Boards: RTD inputs (IS220PRTDH1A), analog-pressure inputs (IS220PAICH1A), discrete I/O packs

GE IS230SNTCH2A integrates with this ecosystem.

Extension components

Pluggable Terminal Blocks: Screw-clamp blocks keyed to prevent mis-insertion, available in shielded variants

DIN-Rail & Panel Mount Kits: Adapter clips and angle brackets for 35 mm rail or panel installation

Shielding Accessories: Cable-shield clamps and ferrite beads for EMI/RFI suppression on thermocouple runs

Calibration Fixtures: External cold-junction and span-adjust testers for on-site verification

All accessories compatible with GE IS230SNTCH2A.

Software support

Configuration & Calibration:

Thermocouple type and filter settings defined via GE ControlST™/ToolboxST™ templates

On-line calibration wizard for zero-offset and span adjustments per channel

Diagnostics & Monitoring:

Open-circuit, short-circuit, and out-of-range alarms reported via HMI and OPC-DA tags

Self-test on power-up with diagnostic flags accessible in controller diagnostics

Firmware Updates: Delivered as part of Mark VIe system releases; applied through ToolboxST™

Documentation: Detailed in the GE Mark VIe/VIeS I/O Installation Guide and Thermocouple Input Module Reference Manual

GE IS230SNTCH2A is fully supported.
