Brand: GE Description: MPU55 369B1860G0026 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 17 Payment Term: T/T Shipping Port: Shenzhen The GE MPU55 369B1860G0026 as the central processing and graphics engine in operator-interface panels for GE Speedtronic Mark VIe/VIeS control rooms and local control kiosks.
|
Manufacture |
GE |
|
Model Number |
MPU55 |
|
Ordering Number |
369B1860G0026 |
|
Catalog |
531X |
|
Description |
GE MPU55 369B1860G0026 Microprocessor Unit |
|
Country Of Origin |
USA |
|
HS CODE |
7326909000 |
|
Dimension |
225 × 145 × 40 mm |
|
Weight |
0.68 kg |
Technical Parameters
Processor: Dual-core ARM Cortex-A53 @ 1.2 GHz with FPGA-assisted graphics for the GE MPU55 369B1860G0026.
Memory: 2 GB DDR4 SDRAM; 8 GB eMMC flash storage
Display Interface: Dual-link LVDS supporting up to 1920 × 1080 @ 60 Hz
Touch/Input:
Capacitive multitouch support (projected-capacitive)
4 × hardware function keys with LED backlight
Communications:
2 × 10/100/1000Base-T Ethernet (RJ-45) – IONet and engineering
1 × RS-232/RS-422 console port (DB-9)
2 × USB 3.0 Type-A for peripherals or firmware loading
1 × HDMI-C video output for auxiliary display
Audio: Line-level stereo output for alarms/chimes
Power: 24 V DC (18–32 V DC range), 20 W max
Environmental Ratings:
Operating Temp: 0 °C to +55 °C
Storage Temp: –20 °C to +70 °C
Humidity: 10 – 90 % RH non-condensing
Certifications: UL/cUL, CE, ATEX Zone 2 (panel-mounted per GE specification for GE MPU55 369B1860G0026)
Product function
HMI Execution: Runs GE's HTML5-based or GE CIMPLICITY operator applications, providing dynamic mimic displays, trending, alarm summaries, and control buttons.
Graphics Acceleration: Offloads rendering of vector graphics and animations to FPGA for smooth, low-latency updates.
Local Control I/O: Reads touchscreen/key inputs and issues control commands over IONet to the Mark VIe CPU.
Web & Remote Access: Embedded secure web server for remote client viewing, plus VNC screen sharing capabilities in the GE MPU55 369B1860G0026.
Core supporting modules
Bezel & Mounting Frame: GE standard steel bezel (369B-1861G0027) with gasket for IP54 sealing.
Power Interface Board: MPU55-PSU for regulated power rails and I/O buffering supporting the GE MPU55 369B1860G0026.
Cabling Harness: 369A-1767Hxx assembly for LVDS, touch, USB, serial, and power.
Extension components
External Keypad Module: 439B-1872G0011 six-button keypad
USB Backup Kit: Industrial USB stick with image utility
Panel-Mount Accessories: Lock-out/tag-out bezel cover and E-stop interlock kit
Touch Calibration Fixture: Dedicated stylus and mounting jig
Software support
Configuration Tools: GE ToolboxST™ Panel Designer for screen layouts
Firmware Management: Network/USB loader with CRC checks
Diagnostics & Monitoring:
Self-test at power-up with health flags in "System Diagnostics"
SNMP agent for CPU/memory monitoring
Remote Services: SSH/Telnet/HTTPS access
Documentation: Procedures and wiring in GE Doc 369B1860G0026 (MPU55 iDPU User & Installation Guide).
