Siemens 6ES7135-6HD00-0BA1

Functional Features

High-density output: 16 digital outputs, saving installation space.

PNP output (source): output high level (+24V) to drive the load.

Integrated diagnostic function: Siemens 6ES7135-6HD00-0BA1 supports short circuit, wire break, overload detection, and displays the status through LED indicators.

Modular design: Siemens 6ES7135-6HD00-0BA1 supports hot plugging, easy maintenance and expansion.

Compatibility: seamlessly cooperates with other modules of the ET 200SP system and needs to be used with the base unit (BaseUnit).

Technical specifications

Load voltage range: 20.4V–28.8V DC

Switching frequency: up to 1kHz (resistive load)

Electrical isolation: no isolation between channels, but isolation between groups (8 channels per group).

Power loss: typical 1.5W.

Product details

Physical characteristics

Color identification: black (typical color of digital output modules).

Wiring method

Wiring through Base Unit, supporting plug-in spring clamp connection.

Certification standards

Complies with international certifications such as CE, UL, ATEX, etc., suitable for industrial environments.

Application areas

Industrial automation

Control loads such as solenoid valves, relays, indicator lights, small motors, etc.

Production line control

Logic output control for equipment such as packaging, assembly, and conveyor belts.

Process Automation

Work with PLC (such as S7-1500/1200) to realize distributed I/O control.

Building Automation

Lighting and ventilation system switch control.

Notes

Compatibility: Siemens 6ES7135-6HD00-0BA1 need to be used with ET 200SP CPU interface module (such as IM 155-6PN).

Configuration tool: Configuration and programming through TIA Portal (STEP 7).

Heat dissipation requirements: Make sure the module works at rated load current to avoid overheating.
