Siemens 6ES7234-4HE32-0XB0

Product Description

Function:

Supports 4 analog signal inputs, which can be configured as voltage (±10V, ±5V, 1~5V, etc.) or current (0~20mA, 4~20mA, etc.).

16-bit high resolution, suitable for high-precision measurement scenarios.

Supports RTD and TC temperature sensor input, with cold end compensation function.

Electrical isolation: There is no isolation between channels, but the module is electrically isolated from the backplane bus.

Diagnostic function: Siemens 6ES7234-4HE32-0XB0 supports disconnection detection, over-range alarm, etc. to enhance system reliability.

Product Details

Technical Parameters

Input Channels: 4

Resolution:

Voltage/current: 16 bits (including sign bit)

Temperature (RTD/TC): 15 bits + sign bit

Accuracy: ±0.1% (voltage/current, typical value)

Sampling time: configurable (default 25ms/channel)

Load capacity: maximum 350Ω load when current input

Supply voltage: 24V DC (through system power module)

Power consumption: typical 1W (when no load)

Operating temperature: -20℃～+60℃

Protection level: IP20 (needs to be installed in the control cabinet)

Module structure

Base unit: Siemens 6ES7234-4HE32-0XB0 needs to be used with Base Unit of corresponding color.

Color identification: light blue (standard color code for analog modules).

Expandability: Siemens 6ES7234-4HE32-0XB0 supports modular expansion of ET 200SP system, with a maximum of 64 modules.

Application fields

Industrial process control:

Acquisition of analog signals such as pressure, flow, and liquid level.

Temperature monitoring.

Energy management: current/voltage monitoring (such as power distribution system, photovoltaic inverter).

Manufacturing industry:

Production line quality inspection (such as force sensor, displacement sensor signal processing).

Environmental monitoring (temperature, humidity, gas concentration, etc.).

Building automation: temperature and pressure feedback in HVAC system.

Advantages and characteristics

Flexibility: Siemens 6ES7234-4HE32-0XB0 supports multiple signal types and reduces the number of spare parts.

High precision: 16-bit resolution meets the needs of precision measurement.

Easy integration: Seamless connection with Siemens PLC via PROFINET or PROFIBUS.

Diagnostic function: Real-time fault detection to reduce the risk of downtime.

Compatibility and selection recommendations

Compatible PLC: Siemens S7-1200/1500, ET 200SP controller, etc.

Supporting software: TIA Portal (STEP 7) is required for configuration and programming.

Alternative models:

6ES7231-4HF32-0XB0

6ES7234-4HE30-0XB0
