Vibration RPS6U 200-582-993-NHH

Product Overview

RPS6U is a dedicated 6U height rack-mounted power module designed by Megite Sensing Systems for the VM600 Mk2 / VM600 condition monitoring and mechanical protection system platform. The RPS6U 200-582-993-NHH is responsible for providing stable, reliable and redundant DC working power for all processing cards, I/O cards and communication cards within the entire VM600 rack. Model 200-582-993-NHH specifically refers to the "DC input version" of the RPS6U power supply, and its Rear Panel has a specific configuration: Order Number (PNR): 200-582-993-NHH

Rear backplane type: This PNR actually refers to the rear backplane assembly used in conjunction with the DC input RPS6U, rather than the power module itself. The key feature of this backplane is that it provides two independent DC power input terminals, allowing for separate power supply to the two RPS6U power supplies within the rack, thereby achieving true power redundancy.

Core function: Convert and distribute the externally provided DC power supply to the VM600 rack backplane to ensure seamless and uninterrupted operation of the system even in the event of a single power failure.

In short, the 200-582-993-NHH is a key infrastructure component for building a highly available, dual-path independent DC-powered VM600 system.

Product Specifications and Parameters

Product type                                              VM600 Mk2/VM600 system DC input type backplane assembly

Order number PNR                                     200-582-993-NHH

Corresponding VM600SYS option codes        F993,F930

Power input

Quantity                                                   2 independent DC inputs

Interface                                                  Screw-terminal connectors

Power supply mode                                   Provide independent input for the two RPS6U power supplies within the rack

Redundancy support                                 Supports fully redundant external power supply systems. PS1 and PS2 can be powered by two physically independent DC power supplies.

Circuit protection                                      The rear backplate itself does not contain circuit protection for DC input. Users must install circuit breakers or fuses with appropriate rated values on the external power supply side.

Applicable power module                          Specifically designed for DC-input version of RPS6U.

Physical dimensions                                  Compatible with a standard 19-inch rack, with a height of 6U.
