EA402 913-402-000-01-A2-E090-F0-G000

Core parameters and features:

The Vibro-Meter 913-402-000-01-A2-E090-F0-G000 extension cable has the core advantage of passing Exi explosion-proof certification (compliant with ATEX, IECEx, North American cCSAus, Korean KGS and Russian EAC certification), ensuring safe operation in potentially explosive environments (0, 1, 2 zones).

Its precise length (9 meters ± 900mm) and low-loss coaxial structure (FEP coating, 3.6mm diameter) ensure high-fidelity transmission of signals from the probe to the transmitter, supporting a wide frequency response of the entire system from DC to 20 kHz (-3 dB).

Meggitt Vibro-Meter EA402 913-402-000-01-A2-E090-F0-G000 extension cable operates stably in a wide temperature range of -40°C to +200°C, is resistant to vibration and shock, and its standardized self-locking micro coaxial interface ensures plug-and-play and component interchangeability with TQ442 probes and IQS450 transmitters, making it an indispensable part of achieving a highly reliable, intrinsically safe machinery monitoring solution.

System Integration and Application:

EA402 913-402-000-01-A2-E090-F0-G000 extension cable is an indispensable part of building a complete, intrinsically safe proximity measurement chain. It is perfectly integrated into vibro-meter® solutions (such as VM600/VibroSmart® systems), and is particularly suitable for monitoring the shaft vibration and axial displacement of key machinery (steam turbines, gas turbines, compressors, pumps) in hazardous areas (such as oil and gas platforms, chemical plants, coal mines) or high-temperature areas (such as near turbomachinery). Its design ensures that when the sensor is deployed in a small space or inaccessible location, the signal can be transmitted to the transmitter without loss, providing a reliable data basis for equipment protection and condition monitoring.
