Brand: GE Description: Relay Output Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: Shenzhen GE DS200TCRAG1ABC Relay Output Board is responsible for emergency trip protection, overspeed release testing and main trip logic control, ensuring high reliability and safety in industrial environments, and supporting real-time response to complex control logic through multi-processor architecture and redundant design.
|
Manufacture |
GE |
|
Model Number |
DS200TCRAG1ABC |
|
Ordering Number |
DS200TCRAG1ABC |
|
Catalog |
Mark V |
|
Country Of Origin |
United States (US) |
|
HS CODE |
8538900000 |
|
Dimension |
24*16*4cm |
|
Weight |
0.6kg |
Product Features
Equipped with three microprocessors and shared RAM, GE DS200TCRAG1ABC supports multitasking and parallel processing to ensure real-time response to complex control logic.
GE DS200TCRAG1ABC monitors critical parameters (e.g., speed, temperature), triggers trips to prevent equipment damage, and synergizes with other control modules to achieve redundant protection.
GE DS200TCRAG1ABC supports electrical overspeed release test, mechanical release piston test, etc. to ensure system safety and reliability.
GE DS200TCRAG1ABC has on-board 10 LEDs that display fault codes in different combinations for quick troubleshooting.
GE DS200TCRAG1ABC supports jumper settings for coil current (10-120mA) and resistance range (22Ω-1000Ω), adapting to different servo valve requirements. It also supports RS485 and Ethernet (Modbus TCP/IP, SRTP protocol) for real-time data interaction.
Product Working Principle
GE DS200TCRAG1ABC receives sensor signals (e.g. LVDT position feedback, pulse rate input) through terminal boards (e.g. DS200TBQBG1ACB), which are analyzed by the microprocessor to generate control commands.
When an abnormality such as overspeed or overcurrent is detected, the ETR or PTR relay is triggered to cut off the power source of the turbine, and at the same time, the fault code is displayed through the LED indicator.
Its TMR architecture ensures fault tolerance for critical control paths and improves system stability.
GE DS200TCRAG1ABC verifies the effectiveness of trip circuits by activating test functions through software or hardware commands.
Product Parameter
GE DS200TCRAG1ABC specification data as below.
Power Supply: 24V DC (typical), input range 18-32V DC
Communication Interfaces: RS485, Ethernet (Modbus TCP/IP, SRTP)
Operating Temperature: -40°C to +70°C, suitable for harsh industrial environments
Protection Rating: IP20 (for indoor use, must be installed in a control cabinet)
Output Characteristics: 12-bit analog output, capable of driving actuators such as servo valves
Relay Contact Capacity: 0.5A (maximum)
