Brand: GE Description: SERVO AMP BOARD Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen GE DS3800HSAA1U1N integrates microprocessor and signal processing functions for high-precision servo control and signal conditioning, and supports triple modular redundancy (TMR) architecture to ensure reliability and fault tolerance in critical industrial applications.
|
Manufacture |
GE |
|
Model Number |
DS3800HSAA1U1N |
|
Ordering Number |
DS3800HSAA1U1N |
|
Catalog |
Mark IV |
|
Country Of Origin |
United States (US) |
|
HS CODE |
8543709990 |
|
Dimension |
16*10*6cm |
|
Weight |
0.4kg |
Product Features
GE DS3800HSAA1U1N integrates an analog/digital converter (ADC) and a digital/analog converter (DAC) to support multi-channel signal input and output.
GE DS3800HSAA1U1N has 3 built-in trimming resistors for calibrating the gain and offset of the output signals to ensure high-precision control.
GE DS3800HSAA1U1N supports RS-485 and Ethernet interfaces and is compatible with Modbus protocol for data interaction with host computer or other control systems.
GE DS3800HSAA1U1N is equipped with an EEPROM socket for storing firmware and configuration parameters, and supports on-site firmware update.
GE DS3800HSAA1U1N is equipped with over-voltage and over-current protection circuits, as well as temperature monitoring functions to ensure stable operation of the module in harsh environments.
GE DS3800HSAA1U1N adopts pluggable connectors for easy maintenance and replacement, and the circuit board surface is coated with moisture-proof coating to adapt to industrial-grade environment.
Product Using Principle
GE DS3800HSAA1U1N can receive digital commands from the controller and convert them into analog voltage or current signals through DAC to drive servo motors or hydraulic valves.
GE DS3800HSAA1U1N can also collect analog feedback signals from sensors and convert them into digital signals through ADC for controller analysis.
GE DS3800HSAA1U1N has a built-in PID algorithm to process the feedback signals and dynamically adjust the output signals to eliminate errors and realize accurate tracking.
GE DS3800HSAA1U1N can store the calibration parameters through EEPROM and support manual adjustment of the field fine-tuning resistors to ensure system consistency.
GE DS3800HSAA1U1N can exchange data with the upper computer or other modules via RS-485 or Ethernet to support remote monitoring and fault diagnosis.
Product Parameter
The following detail is for GE DS3800HSAA1U1N SERVO AMP BOARD.
|
Parameter |
Specification |
|
Power Input |
100-240V AC, 50/60Hz, supporting redundant dual power supply |
|
Processing Speed |
100MHz microprocessor, supporting real-time data processing and fast response |
|
Memory |
512MB RAM, 4GB flash memory for program storage and data recording |
|
I/O Types |
Analog input: 4-20mA, 0-10V (specific number of channels not specified) Digital output: relay or transistor driven |
|
Communication Protocols |
Modbus RTU (RS-485), Modbus TCP (Ethernet), supporting custom protocol extension |
|
Operating Temperature |
-40°C to +85°C (storage temperature) 0°C to +70°C (operating temperature) |
