Brand: GE Description: AC Voltage Output Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen GE IC693MDL340 AC Voltage Output Module core function is to convert 24V DC switching signals from field devices into digital signals that can be processed by the PLC for condition monitoring (e.g. equipment start/stop, position detection, etc.).
|
Manufacture |
GE |
|
Model Number |
IC693MDL340 |
|
Ordering Number |
IC693MDL340 |
|
Catalog |
GE Fanuc Series |
|
Country Of Origin |
United States (US) |
|
HS CODE |
8538900000 |
|
Dimension |
12*8*6cm |
|
Weight |
0.2kg |
Product Features
GE IC693MDL340 has a high-density design with 32-point inputs (industrial-grade compact module).
GE IC693MDL340 has group isolation, 4 groups × 8 points, galvanic isolation between groups (250V AC/DC), no isolation between points within groups. Optocoupler isolates input circuit from PLC backplane logic.
GE IC693MDL340 is compatible with wide voltage, supporting 10-30V DC input (compatible with 24V industrial standard).
GE IC693MDL340 is fast response with switching delay ≤ 1ms (ON/OFF switching).
GE IC693MDL340 has LED status indication, each point independent green LED shows input status (ON/OFF).
GE IC693MDL340 has low power consumption, about 5mA current per point (at 24V DC).
Product Working Principle
Signal Input: 24V DC signals from external devices (e.g. sensors, pushbuttons) are connected to the module terminals.
Level detection:
≥10V DC → Judge as ON (logic “1”), light up the green LED.
≤3V DC → Judge as OFF (logic “0”), LED off.
Isolation conversion: optocoupler isolator separates field signals from PLC internal circuits to prevent interference.
Data transmission: status data is transmitted to the CPU via the backplane bus for program logic processing.
GE IC693MDL340 key design points that 8 points in the group share the same circuit (need to unify the power polarity), independent isolation between groups can be connected to different power sources.
Product Applications
In the manufacturing industry, GE IC693MDL340 enables equipment status monitoring (motor operation, valve position).
In automotive production lines, GE IC693MDL340 can be used as a position sensor (limit switch, photoelectric detection).
In material transportation, GE IC693MDL340 is responsible for conveyor start and stop, goods in place detection.
In the energy system, GE IC693MDL340 can judge the status of circuit breaker, alarm contact collection.
In building automation, GE IC693MDL340 can provide feedback on the status of fire-fighting equipment.
Product Parameter
GE IC693MDL340 specification data as below.
|
Item |
Specification |
|
Number of Input Points |
32 points |
|
Input Type |
Sink type / NPN compatible |
|
Rated Voltage |
24V DC |
|
Logic "1" Level |
≥10V DC |
|
Logic "0" Level |
≤3V DC |
|
Input Impedance |
Approximately 4.7kΩ |
|
Maximum Surge Protection |
35V DC for 0.5 seconds continuously |
|
Backplane Current Requirement |
5V DC @ 120mA (logic side power supply) |
|
Operating Temperature |
0°C to 60°C |
