Brand: GE Description: IS200STCIH4A Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 21 Payment Term: T/T Shipping Port: Shenzhen GE IS200STCIH4A DIN Rail Contact Input Card These boards serve as the field-wiring interface for high-channel-count discrete contact inputs within GE Speedtronic Mark VIe/VIeS I/O racks.
|
Manufacture |
GE |
|
Model Number |
IS200STCIH4A IS200STCIH4ADD |
|
Ordering Number |
IS200STCIH4A IS200STCIH4ADD |
|
Catalog |
Mark VIe |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
178 × 330 × 160 mm |
|
Weight |
0.5 kg |
Technical Parameters
GE IS200STCIH4A DIN Rail Contact Input Card
Channels: 32 isolated contact inputs
Input Type: Dry‐contact closure detection with external excitation
Nominal Wetting Voltage: 24 V DC (18–32 V DC range)
Input Current: 2.5 mA per channel (nominal)
Debounce/Filtering: 4 ms hardware debounce on all channels
Isolation: Reinforced channel-to-channel and channel-to-ground (> 1 kV)
Connectors: Right-angle header for 52-position pluggable terminal block
Status Indicators: Per-channel LED for contact-closed status
Operating Temp: –30 °C to +65 °C
Storage Temp: –40 °C to +85 °C
Humidity: Up to 95 % RH, non-condensing
Coating (4ADD): Class D conformal coating for enhanced resistance to moisture, salt spray, and chemical contaminants
Product function
GE IS200STCIH4A Breaks out discrete-I/O-pack backplane signals to rugged, isolated terminals for field wiring. Each channel monitors a dry-contact input and reports its status over the IONet bus to the Mark VIe CPU, enabling reliable detection of safety interlocks, limit switches, and auxiliary contacts with hardware-level noise suppression.
Core supporting modules
Discrete-Input Pack: IS200TICIH2A–H series I/O pack carrier
Controller Module: Mark VIe CPU (e.g., IS200TPROH1C)
Complementary I/O Boards: Relay outputs (IS400TRLYS1B), analog inputs (IS220PTCCH1B, IS230STTCH2A), safety I/O (IS220YSILS1B)
Extension components
Terminal Blocks: 52-way screw-clamp pluggable blocks, keyed to prevent mis-insertion
Mounting Hardware: Angle brackets for DIN-rail (35 mm) or panel mounting
Shielding Accessories: Cable-shield termination clamps and ferrite cores for EMI/RFI suppression
Conformal-Coating Service Kit: Field-service kit for applying or renewing coating on standard boards
Software support
Configuration: None—fully passive, hardware-based input conditioning
GE IS200STCIH4ADiagnostics & Monitoring:
Channel-open and stuck-contact conditions reported via controller diagnostics and HMI alarms
Real-time contact-status flags accessible through OPC-DA tags
GE IS200STCIH4AFirmware: Not applicable
Documentation: Detailed in the GE Mark VIe/VIeS I/O Installation Guide and the “Discrete Contact-Input Terminal Board” section of the I/O-Pack Reference Manual
