Brand: GE Description: Simplex Contact Input with Group Isolation Terminal Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 5 Payment Term: T/T Shipping Port: ShenZhen GE IS210DTCIH1A is a simplex contact input terminal board. It provides 24 discrete contact input channels and 24 VDC excitation voltage to ensure accurate signal processing for industrial applications. It features bank isolation for enhanced safety and system reliability.
|
Manufacture |
GE |
|
Model Number |
IS210DTCIH1A |
|
Ordering Number |
IS210DTCIH1A |
|
Catalog |
Mark VI |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
30cm*18cm*10cm |
|
Packing Dimension |
32cm*20cm*12cm |
|
Weight |
1.2kg |
Operating Parameters
Input Voltage: 24V DC
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95%
Communication Protocol: Supports industry-standard protocols such as Modbus, Profibus, or Ethernet.
Power Consumption: Low power design, typically under 10W.
I/O Channels: Multiple digital input and output channels for versatile connectivity
Product Features
Designed for high reliability: GE IS210DTCIH1A Capable of functioning in challenging industrial environments with resistance to vibration, temperature variations, and electromagnetic interference.
Modular Design: GE IS210DTCIH1A Enables easy replacement and upgrades, minimizing downtime across the entire system.
Advanced Diagnostic: Real-time Monitoring and Fault detection with Embedded Diagnostic.
Compatibility: Fully compatible with other Mark VI series components and GE control systems.
Scalability: Ability to extend for further I/O modules communication interfaces.
I/O Channels: it Includes signals for digital In and Out, which allows for various control configurations.
Discrete Input Processing: The GE IS210DTCIH1A can process contact input signals from field devices, ensuring their status information is sent to the control system for monitoring and decision-making.
Group Isolation: The GE IS210DTCIH1A offers Group Isolation that enhance system safety and minimize risk of crosstalk across channels.
Installation
Pree Installataion: Make Sure Power Supply Should Be Off Ensure GE IS210DTCIH1A works in tandem with the current control system. Check the module for any signs of physical damage.
Mount: Fix the module on a DIN rail or mounting panel in the control cabinet. Keep good ventilation and spacing to avoid overheating.
Linkage: 37 pins female with latching fasteners connected to a VCCC or VCRC controller board for proper communication.
Field Wiring: inputs are brought out to the board for field-contact input and are clearly marked for easy installation.
Application range
Power Generation: Turbine control, generator monitoring and grid synchronization.
Oil and Gas: Pipeline monitoring, compressor control, and safety system.
Manufacturing: Process automation, machine control and quality assurance
Transportation: Marine and raft driving systems
Renewable Energy: Wind turbine control and solar power management
Water Treatment: Monitoring and control of the pump and the process.
Troubleshooting
No Input Signal Detected: Wiring that is loose/disconnected, devices in the field that are defective, or misconfigured settings. Check all wiring connections, field devices operation and configuration settings.
Signal Drops/Intermittent Signal: Electrical noise interference, unstable power supply or bad connectors. Check the installation environment for sources of electrical noise, set a stable power supply, and examine connectors for wear or corrosion.
Over temperature: Low air flow, ambient temp above max. or HIGH current. Provide adequate ventilation around the board, operate within specified temperature range, and check that currents are acceptable.
