GE IS215VCMIH2BC

Operation Parameters

Power Supply: 5V, 12V, 15V, and 28V

Processor: Texas Instruments 32 - bit digital signal processor (DSP)

Frame Rate: 20 ms at 50 Hz

Operating Temperature Range: - 40 °C to + 85 °C

Storage Temperature Range: - 40 °C to + 95 °C

Relative Humidity: 5% to 95% non - condensing

Signal Processing: Capable of handling high-speed signal processing for real-time control and monitoring.

Power Consumption: Low power consumption design to ensure energy efficiency and reduce heat generation.

Product Features

VME Bus Master Controller: The GE IS215VCMIH2BC is a VME bus master controller board. It serves as an important communication interconnect between the input/output boards and the controller. It oversees the communication of data transfer and other protocols between these components in this capacity, assuring seamless operation.

System control network interface: GE IS215VCMIH2BC also serves as the interface to the Ionet, or system control network. This allows it to communicate with other control modules in the system. In a big - scale industrial setup, this enables to To exchange important data such as management, regimen, and diagnostic information between individual portions of the control system.

Board Identification and Management: When the GE IS215VCMIH2BC is linked to I/O and control racks, it manages the identification of all the boards in the rack, as well as the terminal board in those racks. It manages things at the board - level which acts as a bridge between the overall system configuration and maintenance, with its help, it becomes easy to track and manage every component in the Industrial control at a system level.

Real-Time Monitoring: Provides real-time data acquisition and monitoring for turbine control systems.

Protection Features: Includes overvoltage, overcurrent, and thermal protection to safeguard the system.

Installation

Rack Dimensions: The GE IS215VCMIH2BC is a rack mountable part type and will be inserted into a typical VME rack. However, it is a 6U high VME board, 0.787 inches wide, which allows fitting in standard rack dimensions widely used in industrial control cabinets.

Connecting to Other Parts: Connect the board with the I/O boards and the controller with the proper cables. You need to set up your Ionet connection to communicate with the system control network. In a TMR, great attention must be paid to the correct wiring and configuration of all the multiple control modules that are present.

Software Configuration: After the hardware installation, there may be need for the software configuration. This includes creating communication protocols, mapping of input / output, and other system - dependent parameters. Call out the right version of ID and Toolbox software.

Application range

Gas and Steam Turbine Control: These are crucial for power plant's turbine operations and their control and monitoring.

Industrial Automation: GE IS215VCMIH2BC Utilized in control systems of process industries like oil and gas, chemical and manufacturing.

Power Generation: Ensures that all power generation systems operate as efficiently and reliably as possible.

Diagnostic Systems: Real time monitoring and diagnostics for preventive maintenance

Protection Systems: Placed as an essential device within the turbine protection systems, its operative state serves to mitigate damage-effects during unexpected scenarios.

Troubleshooting

Communication Failures: VME backplane connection problems or interference causing communication issues. Seat the board firmly and reduce electrical noise sources if you can.

Application Errors or Failures: Can be caused by misconfigurations or defects in software components. Check the system configuration and test the components to locate and fix the issue.
