Brand: GE Description: Analog Output Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 6 Payment Term: T/T Shipping Port: ShenZhen GE IS220PAOCH1B is a 6-channel analog output module designed for GE Mark VIe control systems. It converts digital commands into precise analog output signals, enabling accurate control of industrial processes.
|
Manufacture |
GE |
|
Model Number |
IS220PAOCH1B |
|
Ordering Number |
IS220PAOCH1B |
|
Catalog |
Mark VIe |
|
Country Of Origin |
USA |
|
HS CODE |
7326909000 |
|
Dimension |
12.2cm*8.2cm*6cm |
|
Packing Dimension |
15cm*11cm*8cm |
|
Weight |
0.4kg |
Operating Parameters
Power Supply: 28V DC power source.
Operating Voltage: 0-30V DC
Number of Channels: 6
Output Type: Analog
Rated Current: 1A per channel
Communication Protocol: Modbus RTU
Power Consumption: 5.3 W
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Input/Output Signal Handling: Each point on the module can accept 2 wires of 3.0 mm²
Product Features
Analog and Digital Signal Processing: The GE IS220PAOCH1B facilitates processing of both analog and digital signals from field devices for accurate data acquisition and control.
Data Communication: GE IS220PAOCH1B enable the interaction between the control system and the field devices through Ethernet or underlying communicational systems.
Redundancy Support: GE IS220PAOCH1B Built to operate with redundant configurations for HA systems
Diagnostics: Specialized diagnostic features for monitoring system health and detecting faults.
Analog Signal Output: The most important function of the GE IS220PAOCH1B is that it outputs analog signals. It successfully converts the stored data to its respective equivalent in an analog form that can be properly interpreted by the machinery.
Control Network Communication: Directly on the IONet, dedicated, full duplex, point to point protocol. It also enables exchanging data with the system I/O components and the main processor.
Installation
Mounting: The GE IS220PAOCH1B is typically mounted on a DIN rail within a control cabinet. Ensure proper spacing for ventilation and accessibility.
Power Supply: Verify that a stable 24V DC power supply is given to the module. Check polarity to prevent damage.
Grounding: Ensure that the module and any related gear are grounded correctly to avoid electrical interference and maintain safety.
Configure: The GE ToolboxST software to configure the module and incorporate it into the control system.
Application range
Power Generation: Hydroelectric Plants, Gas Turbines, Steam turbines.
Energy: Monitoring of pipelines, compressor management, and offshore facilities.
Industrial Automation: Process control, manufacturing and material handling.
Renewables: Wind turbine controllers and solar generation systems.
Troubleshooting
No Power: Check that the power supply is connected properly and that 24V DC power is present. Make sure fuse or circuit breaker in which fridge was connected is not blown.
Inspection for Communication Failure:Inspect the physical components of the Ethernet cables and connectors for potential damage. Verify that the IP address and network configuration are correct.
I/O Channel Malfunction: Check the wiring between the field devices. Inspect terminals for looseness or corrosion.
Module Not Detected:Re-insert the module in its slot. GE ToolboxST software is used to flash the firmware updates.
Overheating:Provide module Proper venti Look for too much ambient temperature.
Diagnostic Alarms:Use ToolboxST diagnostic tools to identify specific fault codes and take corrective action.
