Brand: GE Description: Primary Turbine Protection DIN Rail Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 5 Payment Term: T/T Shipping Port: Shenzhen GE IS230TNTRH1C is specially designed for power equipment such as gas turbines and steam turbines. It is responsible for collecting key operating parameters of the turbine (such as temperature, pressure, speed, etc.), and feeds back the processed signals to the control system to achieve precise speed regulation, safety protection and status monitoring.
|
Manufacture |
General Electric |
|
Model Number |
IS230TNTRH1C |
|
Catalog |
Mark VI |
|
Country Of Origin |
USA |
|
HS CODE |
9031809090 |
|
Dimension |
16*9*7CM |
|
Packing Dimension |
20*11*10CM |
|
Weight |
1.5kg |
Technical parameters
Input voltage: 24V DC.
Signal processing: supports analog (±10V/4-20mA) and digital input, with a resolution of 16 bits and an accuracy of ±0.1% full scale.
Protection level: IP20 (dust-proof design, suitable for installation in control cabinets).
Operating temperature: -20℃ to +70℃, storage temperature -40℃ to +85℃.
Communication rate: Supports Modbus RTU/TCP, EtherNet/IP protocols, and the data transmission rate reaches 100Mbps.
Functional features
Signal acquisition and processing: Receive turbine sensor signals (such as thermocouples, vibration probes) through a multi-channel interface and convert them into digital signals through a high-speed ADC.
Redundant control: GE IS230TNTRH1C supports dual network redundant architecture, and the main and standby switching time is ≤50ms to ensure continuous operation of the system.
Diagnosis and protection: Real-time monitoring of signal abnormalities (such as over-limit, disconnection), triggering alarms or emergency shutdown (ESD) protection.
Working principle
GE IS230TNTRH1C is integrated into the Mark VIe control rack through the backplane connector. After receiving the field sensor signal, the built-in processor performs filtering, scaling conversion and other processing, and then uploads it to the central controller through the Ethernet or serial interface. At the same time, reverse control instructions (such as adjusting the valve opening) are executed to maintain the stable operation of the turbine.
Compatibility and supporting products
IS200TTURH1CFD: The same series of terminal turbine plate, used for signal expansion.
IS230STAOH2A: Digital I/O module, used to drive actuators.
Third-party equipment: GE IS230TNTRH1C supports communication with Siemens SIMATIC S7-1500 and Schneider Modicon series through Modbus protocol.
Sensor adaptation: Can be connected to Bently Nevada 3500 series vibration monitoring instruments.
