Brand: Siemens Description: Digital output module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 1 Payment Term: T/T Shipping Port: Shenzhen Siemens 6ES7132-6BF01-0BA0 SIMATIC ET 200SP, Digital output module, DQ 8x 24V DC/0,5A Standard, Source output (PNP,P-switching)
|
Manufacture |
Siemens |
|
Model Number |
6ES7132-6BF01-0BA0 |
|
Catalog |
SIMATIC ET 200SP |
|
Country Of Origin |
Germany |
|
HS CODE |
8538900000 |
|
Dimension |
1.5cm×7.3cm×5.8cm |
|
Packing Dimension |
3.5cm×9.3cm×7.8cm |
|
Weight |
0.03kg |
Technical parameters
Electrical characteristics
Output type: transistor (source output, P-MOSFET)
Rated voltage: 24V DC
Rated current per channel: 0.5A
Total module current: 2A (total of all channels)
Load impedance range: 48Ω ~ 4kΩ
Isolation method: no isolation between channels, isolation between groups (8 channels per group)
Communication and configuration
Compatible bus: PROFINET (connected via ET 200SP interface module)
Configuration tool: STEP 7 (TIA Portal) / GSD file import
Module type: hot-swappable
Mechanical characteristics
Module width: 15mm (compact design)
Wiring method: fast wiring via BaseUnit (BU), support push-in spring connection.
BaseUnit matching: BU type is required.
Diagnostic function
Siemens 6ES7132-6BF01-0BA0 supports short circuit detection and wire break detection.
Fault information can be displayed via PLC or HMI.
Product Features
Efficient and compact: 16 channels are integrated in a 15mm width, saving space in the control cabinet.
Flexible expansion: The ET 200SP system supports modular expansion and can be installed in a mixed manner with digital/analog modules.
High reliability: hot-swappable, no downtime required for maintenance.
Simplified wiring: The BaseUnit design reduces wiring time and reduces error rates.
Application areas
Industrial automation
Siemens 6ES7132-6BF01-0BA0 controls solenoid valves, cylinders, motor starters, etc. on production lines.
Drives signal devices such as indicator lights and alarms.
Process control
Valve control for industries such as chemicals and water treatment.
Logistics and packaging
Sorting systems, conveyor belt control.
Automotive manufacturing
Assembly lines, robot peripheral equipment control.
Notes
Load matching: Ensure that the external load current does not exceed 0.5A/channel and the total current does not exceed 2A.
Protection measures: Siemens 6ES7132-6BF01-0BA0 is recommended to add fuses or diodes to protect inductive loads (such as relay coils).
Environmental conditions: Operating temperature range -20°C ~ +60°C, avoid strong electromagnetic interference environment.
