Brand: Siemens Description: Digital output module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 1 Payment Term: T/T Shipping Port: Shenzhen Siemens 6ES7132-6BH01-0BA0 SIMATIC ET 200SP, Digital output module, DQ 16x 24V DC/0,5A Standard, Source output (PNP,P-switching).
|
Manufacture |
Siemens |
|
Model Number |
6ES7132-6BH01-0BA0 |
|
Catalog |
SIMATIC ET 200SP |
|
Country Of Origin |
Germany |
|
HS CODE |
8538900000 |
|
Dimension |
1.5cm×7.3cm×5.8cm |
|
Packing Dimension |
3.5cm×9.3cm×7.8cm |
|
Weight |
0.03kg |
Key Features
Number of channels: 16 digital outputs
Output type: transistor (source output, PNP)
Rated voltage: 24V DC
Rated current per channel: 0.5A
Total module current: Maximum 4A (total of all channels)
Switching frequency: Maximum 100Hz (resistive load)
Electrical isolation: No isolation between channels, isolation between groups (8 channels per group)
Diagnostic function: Siemens 6ES7132-6BH01-0BA0 supports short circuit, wire break, overload detection (need to be matched with appropriate base unit)
Module width: 15mm (compact design)
Connection method: Wiring through BaseUnit (base unit), such as BU15-P16+A0+2D.
Compatibility
System integration: Compatible with PROFINET or PROFIBUS network (need to be matched with corresponding interface module, such as IM155-6).
Programming support:Siemens 6ES7132-6BH01-0BA0 can be configured and programmed through Siemens TIA Portal (STEP 7).
Product details
Module structure:
Adopts the plug-in design of ET 200SP and needs to be used with the base unit (BaseUnit) and server module.
Color identification: light green (typical DQ module color).
Load capacity:
Siemens 6ES7132-6BH01-0BA0 can directly drive solenoid valves, small relays, LED indicators, etc.
Siemens 6ES7132-6BH01-0BA0 supports inductive loads (protection circuits such as freewheeling diodes are required).
Environmental conditions:
Operating temperature: -20°C to +60°C
Protection level: IP20 (indoor installation only).
Application areas
Industrial automation control:
Production line logic control (such as conveyor belts, sorting systems).
Actuator control of packaging machinery and textile equipment.
Process automation:
Valve control, pump start and stop signal output.
Building automation:
Lighting control, ventilation system switch signal.
Automobile manufacturing:
Signal control of robot end tools.
Advantages
High density: 16-channel compact design saves control cabinet space.
Flexible expansion: Easily expand the number of I/O points through the ET 200SP system.
Diagnostic function: Reduce downtime and improve maintenance efficiency.
