Siemens 6ES7232-4HD32-0XB0

Technical Parameters

Siemens 6ES7232-4HD32-0XB0 Key Features

Number of channels: 4 isolated analog outputs.

Signal Type:

Voltage output: ±10 V, 0~10 V, 1~5 V (programmable)

Current output: 0~20 mA, 4~20 mA, ±20 mA (programmable)

Resolution: 16 bits (including sign bit), high-precision output.

Load capacity:

Current output: maximum 500 Ω load

Voltage output: minimum 1 kΩ load

Accuracy: ±0.3% (full scale).

Electrical isolation: isolation between channels and between channels and backplane bus.

Module width: 35 mm (standard ET 200SP module size).

Power supply: powered by system power supply or external 24 V DC.

Communication and configuration

Compatibility:

Siemens 6ES7232-4HD32-0XB0 supports PROFINET or PROFIBUS-DP (need to be used with corresponding interface modules).

Seamless integration with PLCs such as SIMATIC S7-1500 and S7-1200.

Configuration tool: configure parameters through TIA Portal (STEP 7) software.

Other features

Diagnostic function: supports fault diagnosis such as short circuit, wire break, and over-limit.

Hot swap: supports module replacement during operation (system support required).

Product details

Terminal design: uses ET 200SP's unique color-coded terminal module (BaseUnit) to simplify wiring.

LED indicator: displays the status of each channel (green/red).

Environmental conditions:

Working temperature: -20°C ~ +60°C

Protection level: IP20 (needs to be installed in a control cabinet).

Application areas

Siemens 6ES7232-4HD32-0XB0 is widely used in industrial automation scenarios that require high-precision analog control, such as:

Process control: regulating valves, inverter speed control.

Manufacturing: drive servo systems, temperature control.

Energy management: power output regulation.

Test equipment: analog sensor signal output.
