Brand: Siemens Description: Analog Output SM 332 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 1 Payment Term: T/T Shipping Port: Shenzhen Siemens 6ES7332-5HF00-0AB0 SIMATIC S7-300, Analog output SM 332, isolated, 8 AO, U/I; diagnostics; resolution 11/12 bits, 40-pole, removing and inserting possible with active backplane bus
|
Manufacture |
Siemens |
|
Model Number |
6ES7332-5HF00-0AB0 |
|
Catalog |
SIMATIC S7-300 |
|
Country Of Origin |
Germany |
|
HS CODE |
8538900000 |
|
Dimension |
4.0cm×12.5cm×11.7cm |
|
Packing Dimension |
6.0cm×14.5cm×13.7cm |
|
Weight |
0.272kg |
Product Description
Function:
Provides 32 digital outputs for controlling external devices.
Adopts transistor output (MOSFET),Siemens 6ES7332-5HF00-0AB0 supports high-frequency switching operation, and is suitable for occasions requiring fast response.
Source output (Source Current): The output terminal provides positive voltage (24V), and the load needs to be grounded.
Electrical isolation:
Group isolation between channels, optoelectronic isolation between groups and backplane bus.
Product details
Key parameters
Output type:Transistor (MOSFET), source (PNP)
Rated load voltage: 24V DC (-15%/+20%)
Maximum output current per channel: 0.5A
Total module maximum output current: 4A (total of all channels)
Switching frequency: Up to 1kHz (resistive load)
Power consumption (typical): 2W
Backplane bus current consumption: 50mA
Connection method: Front connector
Mechanical characteristics
Dimensions: 40mm × 125mm × 120mm (width × height × depth)
Weight: about 300g
Mounting method: DIN rail installation
Environmental conditions
Operating temperature: 0°C to +60°C
Protection level: IP20 (indoor installation only)
Application areas
Industrial automation control:
Production line logic control.
Material conveyor systems (conveyor belts).
Process control:
Solenoid valve control (hydraulic/pneumatic system).
Alarm indicator or buzzer drive.
High-frequency switching scenario:
Pulse control that requires fast response.
Advantages and features
High-density output: 32 channels save control cabinet space.
Reliability: short circuit protection, overload protection and reverse polarity protection.
Compatibility: Seamless integration with SIMATIC S7-300 series PLC, support STEP 7/TIA Portal programming.
Notes
Load type:Siemens 6ES7332-5HF00-0AB0 applicable to resistive load and inductive load.
Heat dissipation requirements: Module heat dissipation or derating should be considered for high load current.
Ordering information:Siemens 6ES7332-5HF00-0AB0 front connector must be ordered separately.
