Siemens 6ES7515-2TN03-0AB

Product Description

Siemens 6ES7515-2TN03-0AB is a high-performance CPU module of Siemens SIMATIC S7-1500 series, belonging to the CPU 1515-2 PN model.

Positioning: mid-to-high-end controller, suitable for complex automation tasks.

Core features: Siemens 6ES7515-2TN03-0AB support PROFINET communication, powerful processing power, large memory, suitable for industrial automation control scenarios.

Product Introduction

Key Features

Processor performance:

Execution time of bit instructions is about 1ns, supporting high-speed logic and arithmetic operations.

Memory configuration:

Working memory: 1 MB (for program and data).

Integrated loading memory: 8 MB (expandable through SIMATIC memory card).

Communication interface:

2×PROFINET port: support Gigabit Ethernet, including IRT (isochronous real-time) function, suitable for real-time applications such as motion control.

Siemens 6ES7515-2TN03-0AB support OPC UA, TCP/IP, HTTP and other protocols.

Expansion capability:

Support up to 32 modules (including I/O, communication modules, etc.).

Motion control:

Integrated PID control function, can be connected to servo drive for precise control.

Programming environment

TIA Portal (Totally Integrated Automation Portal) software is required for configuration and programming, supporting multiple languages,such as SCL, LAD, FBD, etc.

Product details

Technical parameters

Power supply voltage: 24V DC (allowable range 19.2V–28.8V).

Power consumption: Typical value is about 10W (depending on configuration).

Digital I/O support: Siemens 6ES7515-2TN03-0AB can be expanded to thousands of points through expansion modules.

Analog processing: requires analog modules (such as 6ES7531-7KF00-0AB0).

Protection level: IP20 (needs to be installed in the control cabinet).

Additional functions

Diagnostic function: Siemens 6ES7515-2TN03-0AB supports module-level diagnosis and network diagnosis, and can be remotely monitored through the Web server.

Safety integration: can be used with Fail-Safe modules to achieve safety functions (such as STOP safety mode).

Application fields

Manufacturing: automotive production lines, packaging machinery, assembly systems.

Process industries: process control in the chemical and pharmaceutical industries.

Logistics automation: warehousing and sorting systems, conveyor belt control.

Energy management: monitoring and scheduling of wind power and photovoltaic systems.

Motion control: CNC machine tools, robot collaborative control (drive system required).

Selection considerations

Expansion requirements: If more I/O points or communication modules (such as PROFIBUS, RS485) are required, additional purchase is required.

Memory card: Siemens 6ES7515-2TN03-0AB is recommended to use Siemens dedicated SIMATIC memory card (such as 6ES7954-8LBxx-0AA0) for program backup.

Heat dissipation requirements: Ensure that the installation environment is well ventilated to avoid high temperature affecting performance.
