Brand: Siemens Description: RS485 Bus Connector Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 1 Payment Term: T/T Shipping Port: Shenzhen Siemens 6ES7972-0AA02-0XA0 SIMATIC DP, RS485 repeater For connection of PROFIBUS/MPI bus systems with max. 31 nodes max. baud rate 12 Mbit/s, Degree of protection IP20 Improved user handling
|
Manufacture |
Siemens |
|
Model Number |
6ES7972-0AA02-0XA0 |
|
Catalog |
SIMATIC DP |
|
Country Of Origin |
Germany |
|
HS CODE |
8538900000 |
|
Dimension |
4.5cm×12.8cm×6.7cm |
|
Packing Dimension |
6.5cm×14.8cm×8.7cm |
|
Weight |
0.35kg |
Product Description
Function:
Siemens 6ES7972-0AA02-0XA0 for physical connection of PROFIBUS DP network, providing terminal resistance and signal relay functions.
Siemens 6ES7972-0AA02-0XA0 supports FastConnect technology to simplify cable stripping and installation process.
Integrated terminal resistance (switchable by switch), suitable for network end nodes.
Physical Characteristics:
Housing Material: High-strength plastic with shielding design.
Interface: 9-pin D-type male/female (depending on the specific application).
Cable connection: via screw terminal or FastConnect plug-in.
Electrical parameters:
Working voltage: 5V (powered by bus).
Maximum current consumption: ≤50 mA.
Protection level: IP20 (suitable for industrial control cabinet environment).
Compatibility:
Compatible with all Siemens PROFIBUS DP devices (such as PLC, ET200 distributed I/O, etc.).
Comply with PROFIBUS international standard (IEC 61158).
Installation method:
Directly plug into the PROFIBUS interface of the device, or connect multiple nodes in series via cable.
Application areas
Industrial automation:
PROFIBUS DP network used to connect Siemens S7-300/400/1500 series PLC.
Communication interface of distributed I/O systems (such as ET200M/ET200SP).
Manufacturing:
PROFIBUS communication for production line control and motor drive (such as Siemens inverter).
Process control:
Bus integration of instrumentation (flow meters, sensors).
Infrastructure:
Networking with other PROFIBUS devices in building automation.
Other considerations
Terminal resistance:
Terminal resistance must be enabled at both ends of the network (set by switches on the connector).
Cable requirements:
It is recommended to use Siemens shielded twisted pair (such as 6XV1830-0EH10).
Alternative models:
6ES7972-0BA12-0XA0 (version with programming port).
