Vibration S3960

Use Parameters

Switch Type and Function: The Vibration S3960 is a rotary switch with 3-pole 6-throw function, allowing circuit configuration and connection.

Electrical Rating: The maximum contact current for AC and DC is rated at 1A. The maximum contact voltage is 115V AC and 28V DC, suitable for low to medium power applications.

Temperature Range: The S3960 operates in a temperature range of -55°C to 125°C, producing excellent credibility even in extreme environmental conditions.

Life and Durability: With an electrical life of 25,000 cycles and a mechanical life of over 100,000 cycles, the device is very reliable and stable.

Product Function

Circuit Control and Configuration: The 3-pole 6-throw function of the Vibration S3960 allows multiple circuit control and configuration at the same time. This enables complex circuit design and flexibility in various applications such as industrial control systems, instrumentation or communication equipment, where multiple signal or power paths need to be properly managed.

Precise Positioning and Switching: The 6-position rotary switch with 60-degree indexing can accurately switch between different circuit states. This is particularly important in applications where precise control and selection of specific functions or parameters are required for reliable and repeatable operation.

Mechanical and Electrical Reliability: The hardened steel sprocket and positioning mechanism consists of ball bearings, which provide very smooth and positive positioning action while also providing the mechanical reliability of the switch. Self-cleaning contacts ensure low contact resistance throughout the service life, reducing the risk of electrical failures and maintaining constant performance.

Compatibility and Integration: The Vibration S3960 is compatible with many systems and equipment. Due to its standard shaft-type actuator and threaded faceplate, it is easy to install and can be easily installed and integrated into existing control panels or enclosures, which immediately reduces installation time and effort.

Scope of Application

Industrial Automation: In industrial automation processes, the Vibration S3960 is used to control and monitor the operation of motors, pumps, valves and other electromechanical devices. Some applications include switching between various operating modes, controlling the speed and direction of a motor, or managing the flow of fluids or gases within a production line; thereby improving the efficiency and reliability of industrial operations.

Instrumentation and Measurement: In instrumentation systems, such as test and measurement equipment, the Vibration S3960 is used to select various measurement ranges, functions, or calibration settings. The machine can be quickly and easily configured and adjusted to meet the requirements of measuring the performance of the test instrument, helping to ensure reliable data acquisition.

Communications and Electronics: In communications and electronic systems, rotary switches can be used to switch power, select various communication channels or frequencies, and configure various operating parameters. Its compact size and good performance make it ideal for use in routers, switches, radios, and other electronic devices in limited spaces where reliable switching is critical.

Medical Equipment: The Vibration S3960 is also widely used in medical equipment, such as patient monitoring, diagnostic equipment, and medical imaging systems. Controlling the operation of different components, selecting measurement modes or parameters, and providing performance under medical reliability and precision conditions are essential to the proper operation of the equipment itself.
